Drawing of a vertical cylindrical gearbox u=5; m=2.5
📂 Drawings
👤 alexey_ktop
Product Description
Assembly drawing of a vertical cylindrical gearbox, module m=2.5 mm, center distance 160 mm, gear ratio u=5. The drawing is made in compass.
